Whether you own a cafe, a design firm, or a tech startup, a reliable and secure network plays a critical role in the success of your business. And you need a network solution that gives you peace of mind, allowing you to focus on growing your business instead of managing problems with your network. Aruba Instant On 1930 makes it easy to keep network users happy, mobile and IoT devices connected, and your network secure. This advanced, smart-managed, fixed-configuration Gigabit Ethernet switch is designed for small businesses. Easy-to-deploy, secure, and affordable, it features anywhere, anytime configuration and management. Using the Aruba Instant On mobile app or the cloud-based web portal, quickly setup, monitor, and manage the Instant On 1930 switch. You can also choose to manage the device through the local web GUI. The JL682A model has 24 RJ-45 10/100/1000 and four SFP 1/10GbE ports.
- Smart-managed Gigabit Ethernet desktop switch offers high-performance connectivity for small businesses
- Features 24 RJ-45 10/100/1000 ports and four SFP 1/10GbE ports
- Quickly setup, monitor, and manage the switch using the Aruba Instant On mobile app, cloud-based web portal, or local web GUI
- Throughput: 95.23Mpps maximum
- Dimensions: 1.73″H x 17.42″W x 8.72″D
- Power consumption: 22.6W maximum, 9.3W idle
- Certifications and standards: Meets or exceeds FCC and UL standards
- Fanless design allows for quiet office deployments
- Switching capacity: 128Gbps
- Memory and processor: ARM Cortex-A9 800MHz; 512MB SDRAM, and 256MB flash with 1.5MB packet buffer
- Operating temperature: 32 to 104 degrees Fahrenheit; operating humidity: 15% to 95%
- Storage temperature: -40 to 158 degrees Fahrenheit; storage humidity: 15% to 95%
- Lifetime manufacturer limited warranty
Specifications
| Address Database Size | 16000 |
|---|---|
| Amperage (amps) | 0.5 |
| Auto-Detecting | Yes |
| Auto-Sensing | Yes |
| Buffer Memory | 1.5MB |
| Data Rate Performances | 128 Gbps |
| Data Transfer Rate | 10/100/1000 Mbps |
| Depth in Inches | 8.72 |
| Full-Duplex | Yes |
| Gaming | Non Gaming |
| Gigabit Ethernet Uplink | Four SFP Fiber Upllinks |
| Height in Inches | 1.73 |
| Input Voltage | 100-127VAC/200-240VAC |
| Jumbo Frame | 9216 Bytes |
| LACP | Yes |
| Layer | 2 |
| Max. Data Transfer Rate (Mbps) | 1000 – 1499 |
| Module Support | SFP, SFP+ |
| Network Management Type | Smart Switch |
| Number of Ethernet Ports | 24 |
| Performance Class | Gigabit Ethernet, Fast Ethernet |
| Port Mirroring | Yes |
| Power Supply | Internal |
| Power over Ethernet | No |
| Protocols | IEEE 802.3/802.3u/802.3ab/802.3z/802.3x/802.1Q/802.1p/802.3ad/802.1X/802.3az/802.1D/802.1W/802.1S/802.1AB |
| Quality of Service | Yes |
| SNMP | v1, v2c, v3 |
| Series or Collection | Instant On 1930 |
| Switch Form Factor | Desktop |
| True Color | White |
| VLAN Support | Yes |
| Warranty Information | Limited Lifetime Warranty |
| Weight (lbs.) | 5.32 |
| Width in Inches | 17.42 |
