Microsemi® PD-9501GI/DC 60 W Single Port Industrial PoE Injector For Network Device

The Microsemi® PD-9501GI/DC single-port industrial PoE injector is a high-power solution for remote powering of current and emerging high-power applications. This PoE injector generates up to 60 W of output power, which is IEEE 802.3at compliant and enables remote powering for a range of applications including 802.11n access point, PTZ cameras and for other IP terminals. The device offers you a plug-and-play installation and supports 10/100/1000 Mbps performance over both 10/100Base-T and 1000Base-T network devices. The design of this industrial injector withstands the temperature within the range of -40 to +75 deg C, hence it is perfect for outdoor applications.

• Industrial PoE injector is a high-power solution for remote powering of current and emerging high-power applications
• Dimensions: 4.4″H x 1.4″W x 3.1″D
• Compatible with 10/100Base-T network devices and 1000 Base-T devices
• Comes in black color
• Interface/ports: 1 x 10/100/1000Base-T input, 1 x 10/100/1000Base-T output, connectors: Shielded RJ-45
• 20 – 60 VDC, 4 A input, 50 VDC PoE output, user port power: 60 W
• Plug and play Installation
• Form factor: Desktop
• Meets RoHS, WEEE, REACH, EN50522 Class A, EN55024, UL508, IEC standards
• Weight: 0.77 lbs.
• Comes with 1 year warranty

Specifications
